ATMOSPHERE LED downlight series represents an innovation in design and technology for architectural lighting. This high lumen and adaptable family of fixtures with a comprehensive set of round and square fittings, affords a sustainable solution for commercial, corporate, and upscale residential applications.

Dim-to-warm color temperature range: 3000K-1800K

Single spot light source

Adjustable LED light engine included with housing: Vertical Adjustment 0-30°, Horizontal Adjustment 365°

Trimless: Die-cast spackle frame included

Exterior trim sold separately

Adjustable LED light engine included with housing: Vertical Adjustment 0-30°, Horizontal Adjustment 365°

Field interchangable beam optics included with housing

1800-3000K Color Temperature options available with housing LED light engine

Refer to specification sheet for lumens and CBCP data

Center beam alignment retained throughout adjustment range

0-45° vertical and 365° horizontal lockable hot aiming

Indexed vertical scaling for precise and accurate alignment

Compatible with a wide range of accessories

Natural and Vivid Precision LED CCT Tuning

Shallow housing under 4in depth

Single spot light source

Adjustable LED light engine included with housing: Vertical Adjustment 0-30°, Horizontal Adjustment 365°

Trimless: Die-cast spackle frame included

Accepts one optional honey comb louver or optical accessory

Exterior trim sold separately

Adjustable LED light engine included with housing: Vertical Adjustment 0-30°, Horizontal Adjustment 365°

Field interchangable beam optics included with housing

2700K, 3000K Color Temperature options available with housing LED light engine

Refer to specification sheet for lumens and CBCP data

Delivered Lumens: 1500lm

CCT: 2700K, 3000K

CRI: 85

Power: 3-25W

Input: 9-15 VAC, 50/60Hz

Rated Life: 70000 Hours

Construction: Corrosion resistant aluminum alloy

Continuously adjustable NEMA beam distribution 3x4 (35° x 60°), 4x5 (60° x 90°), 5x6 (90° x 120°)

Integral brightness control

Rotatable fixture head for vertical distribution

IP66 Rated, protected against powerful water jets

Solid diecast brass or corrosion resistant aluminum alloy

Transformer required

Can be mounted on ceiling or wall in all orientations

Delivered Lumens: 95lm

CCT: 3000K

CRI: 85

Power: 3W

Input: 9-15 VAC, 50/60Hz

Rated Life: 60000 Hours

Construction: Solid die-cast corrosion resistant aluminum

IP66 Rated, protected against powerful water jets

Factory sealed water-tight fixtures

Sleek linear design blends seamlessly into pathways while providing soft, even illumination

Maintains constant lumen output against voltage drop

UL 1838 Listed

Transformer required

Input: 120 VAC, 50/60Hz

Construction: Stainless steel

Outdoor rated stainless steel transformer contains an outdoor rated 3-prong plug for power

Knock outs for power and photosensor connections

3-prong outlet for timer

Taps for 12V, 13V, 14V and 15V

6' lead input wire, except for the 600W which comes with a 5' lead wire

UL 1838 Listed

MLV Dimming capable, dimming dependent upon fixture type

DMX/RDM control

10 DMX/RDM Individual Addressable Output Channels

Dimming Curve adjustment

Selectable control between CCT Tunable and RGBWW

5 Year warranty, Include: 10 X A2L03-072-WT (6 ft. lead wire), 1 X DIN RAIL Stopper

DMX/RDM control

3 DMX/RDM Individual Addressable Output Channels

Dimming Curve adjustment

Selectable control between CCT Tunable and RGBWW

5 Year warranty, Include: 3 X A2L03-072-WT (6 ft. lead wire), 1 X DIN RAIL Stopper

Short Circuit, over current, over voltage, over temperature protection

UL Class 2 Output

3 prongs input power cord plug

Pre-wired output wires ready for DMX LED Controller

DIN Rail & Surface Mount

DIN Rail stopper is included in the package

5 years warranty

This class 2 UL & cUL listed enclosed electronics power supply is one of the most exciting LED power supplies available. What makes this InvisiLED Dim-To Warm power supply unique is that it allows for lowest dimming CCT adjustability among 1800K/1900K/2000K/2100K/2200K right on power supply as you gradually dim the light from 3000K /3500K with InvisiLED Dim-To-Warm.It is compatibles with ELV or 0-10V dimmer. Additionally, it features different kinds of protection from over voltage, short circuit. It is incredibly robust and includes a 5 years warranty. It works with an input voltage of 120-277VAC so you can utilize it for many commercial applications. It features an integrated wiring compartment for a streamlined installation.

May be cut and easily reconnected every 4 inches

Tune to desirable CCT from 1800K to 5000K with DMX/RDM control

Equal brightness for an entire light strip

Strong adhesive bonding with the 3M adhesive VHB

Gold plated connector protects from corrosion, heat, and ensures a reliable connection

May be cut and easily reconnected every 4 inches

Tune to desirable CCT from 2700K to 5000K and visible color spectrum with DMX/RDM control

Equal brightness for an entire light strip

Strong adhesive bonding with the 3M adhesive VHB

Gold plated connector protects from corrosion, heat, and ensures a reliable connection

May be cut and easily reconnected every 4 inches

Select and choose lowest dimming CCT with matching Dim-to-Warm power supply

UV stabilized protective coating protects LEDs and circuitry for long term use in Damp Locations

Connections may be separated and reconnected at each junction point

Equal brightness for an entire light strip

Strong adhesive bonding with the 3M adhesive VHB

Gold plated connector protects from corrosion, heat, and ensures a reliable electrical connection

100ft max distance between the power supply and beginning of Linear Astro Dim-To-Warm

Can be mounted on ceiling or wall in all orientations

Embracing the art of light, a multitude of natural Spanish Alabaster orbs shimmer at different heights from a multi-point canopy, casting an entrancing celestial glow.

A sculpture of interlocking panels render a thought-provoking aesthetic. Barely visible powered aircraft cables add intrigue. The subtle ambient illumination draws attention to this floating work of modern art.

Delivered Lumens: 68lm

CCT: 2700K, 3000K, Amber, Blue, Red

CRI: 90

Power: 3.9W

Input: 120 VAC, 277 VAC, 50/60Hz

ELV Dimming: 100-10%

Rated Life: 50000 Hours

Construction: Die-cast corrosion resistant aluminum alloy

Low profile, flush to wall aesthetics with no visible hardware

Balanced lighting, free of shadows with minimum glare

Up to 200 fixtures can be connected in parallel

Brushed Nickel Finish is for interior use only

Delivered Lumens: 72lm

CCT: 2700K, 3000K, Amber, Blue, Red

CRI: 90

Power: 3.3W

Input: 120 VAC, 50/60Hz

ELV Dimming: 100-10%

Rated Life: 50000 Hours

Construction: Die-cast corrosion resistant aluminum alloy

Can be painted to match the color of the surface

Low profile, flush to wall aesthetics with no visible hardware

Balanced lighting, free of shadows with minimum glare

Up to 200 fixtures can be connected in parallel

Delivered Lumens: 68lm

CCT: 2700K, 3000K, Amber

CRI: 90

Power: 3.9W

Input: 120 VAC, 50/60Hz

ELV Dimming: 100-10%

Rated Life: 54000 Hours

Construction: Die-cast corrosion resistant aluminum alloy

Prevents microbial growth on the surface of the fixture

Low profile, flush to wall aesthetics with no visible hardware

Balanced lighting, free of shadows with minimum glare

Up to 200 fixtures can be connected in parallel

Delivered Lumens: Up to 1100lm

CCT: 3000K, 3500K, 4000K

CRI: 90

Power: 16W, 24 W

Input: 120 VAC, 50/60Hz

ELV Dimming: 100-10%

TRIAC Dimming: 100-5%

Rated Life: 54000 Hours

Construction: Aluminum body, frosted glass diffuser

Back lit with indirect illumination

3CCT (3000K/3500K/4000K) selectable switch

Built in color temperature adjustability.Switch from 3000K/3500K/4000K.

0-10V dimming option (LDS065M010AFE-LO1) available (special order), unit dimensions: 3.4" x 1.2" x 0.5"

ACLED driverless technology

Can be mounted on wall in all orientations
